Klipsch In-Wall Speaker KL7800THX2
Engineered to bring real cinema sound to the comforts of home without taking up valuable floor space, the KL-7800-THX offers the ultimate performance in a hidden solution loudspeaker. It is designed for left, center or right channel use or wherever a monopole speaker is needed.
- THX® Ultra2 certification
- 8-inch aluminum woofer
- 1-inch titanium dome compression driver mated to a square Tractrix® Horn
Because of its THX® Ultra2 certification, the KL-7800-THX works well with multi-channel movie and music presentations playing up to reference levels in rooms of 3,000 cubic feet or larger.
The KL-7800-THX is also capable of delivering the same high-output, low distortion signature sound as its traditional enclosure counterpart, the KL-525-THX. It employs an 8-inch aluminum woofer and a 1-inch titanium dome compression driver mated to a Tractrix® Horn. This advanced horn design dramatically increases efficiency and allows the speaker to produce more output using less energy.
Featuring an integrated back box enclosure, the KL-7800-THX's response is both predictable and repeatable. Because this enclosure fits easily within the loudspeaker's footprint, the KL-7800-THX can be installed into new or existing construction.
Combine this dynamic loudspeaker with Klipsch's KS-7800-THX in-wall surround, KW-120-THX subwoofer and KA-1000-THX subwoofer amplifier to create a variety of THX Ultra2 in-wall system configurations. The KL-7800-THX can also be mixed and matched with the Klipsch THX Ultra2 traditional box products.
Specification | |
---|---|
FREQUENCY RESPONSE: | 80Hz-20kHz 3dB |
SENSITIVITY: | 91dB @ 2.83 volts / 1 meter |
POWER HANDLING: | 150 w max continuous (600 w peak) |
NOMINAL IMPEDANCE: | 8 ohms |
DRIVE COMPONENTS: | Two-way system using one 1" (2.5cm) Titanium dome compression driver in a 5" 80 x 80 Tractrix horn and an 8" Aluminum Cone Woofer |
CROSSOVER FREQUENCY: | 2300Hz |
ENCLOSURE TYPE: | Sealed Enclosure |
HEIGHT: | 20.8" (52.7cm) |
WIDTH: | 11.8" (29.8cm) |
DEPTH: | 3.7" (9.4cm) |
CUTOUT DIMENSIONS: | 19" (48.3cm) x 10" (25.4cm) |
WEIGHT: | 17.5 lbs. (7.9kg) |
FINISHES: | White with Brushed Aluminum Fascia |
INSTALLATION KIT: | IK-802-W (sold seperately) |
BUILT FROM: | 2006 |
