Rockford Fosgate Punch Series 10 Inch Truck Style Powered Subwoofer - P300-10T

Black Friday Price Now

Authorized Dealer Price Match Guarantee

Price Match Guarantee

The Power Centre offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.

Our Price

$599.99 CAD

Or as low as $200.00/month over 3 months. Apply Now

Quote Request

Availability
Call for availability

P300-10T
Best Deal Promise

Literature

Description
Features

The Punch P300-10T is a universal "all in one" solution for dropping Bass in any factory or aftermarket system. This model features a 10" high output woofer with a 300-watt internal amplifier in a slim design enclosure that's great for universal truck applications. The enclosure features quick release input and power connectors for easy removal when extra space is required.

Overview

The Punch 300-10T is a self-contained subwoofer enclosure with built-in amplifier. This "all in one" solution is great for systems that need extra Punch on the low-end of the frequency spectrum. The 10" high output subwoofer is impedance optimized for the built in 300-watt class-D amplifier that features a low-pass crossover, bass EQ and phase switch. The enclosure can be connected via speaker level inputs for connection to factory systems, or traditional line level inputs for aftermarket systems. It also features an intelligent auto turn-on/off circuit that eliminates the need for a separate turn-on wire. The enclosure itself is precision designed and constructed using MDF (Medium Density Fiberboard) for the best acoustical properties and covered with heat activated vinyl finish to resist marks.

High-Efficiency, Low Current Amplifier Design
Optimized 10" Low Impedance Woofer
300 Watt Class-D Amplifier with Optimized "Closed Loop" Design
Adjustable 12db/Octave low pass crossover
On Board Phase Switch
Intelligent auto turn on/off function
Robust Power/Ground connections
Quick Input Connections for Easy Removal
On Board Adjustable Bass EQ
Remote bass level control included
Separate low level and speaker level inputs
Precision Constructed MDF Enclosure with Heat Activated Vinyl Finish
Thermal and over/under voltage protection
Slim Design For Truck Applications
1 Year Warranty

Technologies

CEA-2031

Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.

CEA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards.

Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.

Specifications
Frequency Response	25 Hz to 200 Hz
Woofer Quantity	1
Woofer Size	10"
Woofer Series	Proprietary
Nominal Impedance	—
Power Handling (Watts RMS)	300 Watts RMS
Enclosure Type	Sealed
Enclosure Material	5/8" MDF (Medium Density Fiberboard
Speaker Connector	—
Integrated Amplifier	300 Watts RMS
Crossover Controls	Variable 50 Hz to 200 Hz 12dB/Octave Butterworth
Tone Controls	Bass Boost 0 dB to +12 dB;
Phase Control	0° to 180°
Remote Control	Punch Level Control (Included) Replacement Part: 1510-57864-01
Auto Turn-On Selector	Remote Trigger DC Offset Sense Audio Sense
Input Switch	High-Level (Speaker Line) Low-Level (RCA)
Signal Input	Low/High-Level: 1 RCA Pair (L/R Summed) Replacement Part: 1560-57865-01
Input Sensitivity	Low-Level: 150 mV to 6 V High-Level: 300 mV to 12 V
Input Impedance	20k Ohms
Power Input Connector	Quick Disconnect Replacement Part: 1040-57860-01
Power Wire Gauge	B+/GND: 8 AWG REM: 18 AWG
Circuit Topology Class	Class-D
Heatsink Type	Extruded Aluminum
Cooling	Convection
Visual Indicators	Power/Protect LED
Fuses	20 Amp (2 x 10 Amp ATO Fuse)
Dimensions Box H x W x D Wedge H x W x D1 x D2	13.3" x 21.7" x 4.8" x 7.9" 338 mm x 552 mm x 122 mm x 201 mm
Shipping Weight	25 lbs. (11.3 kg)
